| Product Features | Unit | Parameter | Test Standard |
| Structure | —— | Ceramic Filled Silicon | N/A |
| Color | —— | Grey | Vision |
| Specific Gravity | g/cm3 | 2.8±0.2 | ASTM D792 |
| Thickness | mm | 0.3-10.0 | ASTM D374 |
| Hardness | Shore C | 20-55 | ASTM D 2240 |
| Tensile Strength@1mm | MPa | ≧0.15 | ASTM D412 |
| Elongation at break@1mm | % | ≥60 | ASTM D412 |
| Compression Ratio@ShoreC 25,50psi | % | ≧25 | ASTM D 575 |
| Oil Yield Rate | % | ≦3 | 150℃48h |
| Siloxanes Content(D3-D20) | ppm | ≦200 | EPA 8270E:2018 |
| Flame Retardant Rating | —— | V-0 | UL94 |
| Operating Temperature | ℃ | -40~200 | N/A |
| Thermal Conductivity@3mm,20psi | W/m·K | 3.0±0.2 | ASTM D5470 |
| Thermal Resistance@1mm,20psi | ℃in2/W | 0.57 | ASTM D5470 |
| Breakdown Voltage | kV/mm | ≧6.5 | ASTM D149 |
| Volume Resistivity | Ω·cm | ≧1013 | ASTM D257 |
| Dielectric Constant | @1MHz | ≧5 | ASTM D150 |
| Dielectric Loss | @1MHz | ≦0.1 | ASTM D150 |
| Shelf Life | month | 12 | —— |
